REVO FC

Spectral-Domain OCT | Color Fundus Camera

Find Your Distributor

OCT made simple.

The REVO FC combines the world’s fastest SD-OCT with a non-mydriatic color fundus camera. Featuring our all-new AccuTrack™ real-time hardware-based eye tracker. Operating is as simple as the push of a button.

Jump to section

Tech Specs

Find Out More ⟶

Gallery

Find Out More ⟶

Downloads

Find Out More ⟶

Modules

Find Out More ⟶

The REVOlution continues…

Create your dream all-in-one OCT

1

Full Auto
SD-OCT

With the push of a button, capture posterior and anterior segment OCT scans. A complete toolkit for any clinician.

Learn More ⟶

2

Color Fundus Camera

Includes non-myd color fundus camera for beautiful high-resolution automated retinal imaging.

Learn More ⟶

3

OCT-A Angiography*

This non-invasive dye free technique allows the visualization of the microvasculature of the retina.

Learn More ⟶

4

B-OCT®
Biometry​*

Perform automated measurements of the entire ocular structure and combine a biometer into your OCT.

Learn More ⟶

5

T-OCT™ Topography​*

Detect corneal abnormalities with this pioneering way to capture detailed corneal curvature maps.

Learn More ⟶

6

IOL Calculation*

Keep your library up to date by calculating IOL implant parameters using the latest IOL database standard IOLCon.org.

Learn More ⟶

* Available as optional software module add-on function.

Spectral-Domain OCT

Fully automated capture with the push of the START button.

Moving OCT innovation forward. OPTOPOL pioneered the first Spectral Domain OCT technology 25 years ago. Our background allows us to provide an unparalleled experience to both patients and eye care professionals. Get the best of both worlds with ultra-high quality scans in an easy-to-use interface.

  • Provides both Posterior and Anterior scan capabilities.
  • Combine one-touch exams with preset scan combinations for streamlined workflows.
  • Progression analysis available for detailed analysis over time.
  • Add-on software modules to increase the efficiency of your OCT device.
Previous
Next

Non-Myd Color Fundus Camera

Capture high-resolution 45° true color retinal imaging.

The REVO FC OCT series adds a 12.3 MP Fundus Camera, capable of capturing ultra-high quality color images. The REVO FC series Fundus Camera is fully automated and easy to use.

  • Auto-alignment, auto-focus, auto-flash, auto-capture with the push of a button.
  • Capture high resolution fundus images with a pupil size as small as 3.3 mm.
  • Toolkit of various fundus image processing tools.
  • Deliver detailed photos of one or both eyes as well as a chronological comparison.
  • Save time by attaching a single fundus photo to several OCT scans.
Previous
Next
Previous
Next
NEW

UWF

The UWF lens module provides a new wide perspective of imaging up to ~105º with a single scan. It allows the user to image the macular area along with the far periphery to capture the early stages of disease in the posterior part of the eye. The module allows 3D imaging for full analysis, averaging in enhancement mode, and angio OCT with the ability to visualise perfusion problems in the periphery.

Take your OCT to the next level

REVO FC

AccuTrack™

Our hardware-based eye tracker, compensates for blinks, loss of fixation and involuntary eye movements during scans reducing artifacts.

Auto Functions

Simplifying operation with the push of a button to auto-postion, auto-align, auto-focus, and auto-capture.

A.I. DeNoise

An advanced artificial intelligence (A.I.) algorithm removes noise from the tomogram for the highest image quality.

Custom Scan Protocols

Save time and never miss a scan. Create a custom preset group of scans and let the REVO capture all scans in order.

Motion Correction

The software-based motion correction (MC) compensates for involuntary eye movements and blinks by capturing two scans and generating a motion corrected scan when necessary.

Structure + Function (S+F)

Comprehensive glaucoma solution that combines REVO OCT and PTS Visual Field results. S+F takes the diagnostic approach of the Hood report.

Progression Analysis

Gather baselines and follow-ups to monitor and manage disease progression in posterior and anterior scans.

Network Integration

A proficient networking solution with DICOM and EMR capabilities. Quickly and easily export to a desired location.

Follow disease progression

Full Range

With scans presenting New Extended DepthTM software, based on our Full Range technology, provides scans of increased depth for reliable and convenient observation of challenging cases. With scans presenting extended depth, this new imaging mode is perfect for diagnosing even highly myopic patients.

standardize scans performed

Connectivity

REVO offers an excellent networking solution that allows doctors to view and manage multiple examinations from review stations in your practice. The system comes with the latest version of Windows PRO and can easily export in PDF, JPEG and DICOM formats to your network or EHR.

Follow disease progression

Progression Analysis

Quickly view a chronological set of exams for analysis of changes in morphology, quantified progression maps, and progression trends.

standardize scans performed

Custom Scan Protocols

Save time and never miss a scan. Combine any scan type into a pre-set group. Choose a group of scans and set the order, the REVO will do the rest.

Follow disease progression

Glaucoma Tool Kit

Comprehensive glaucoma analytical tools for quantification of the Nerve Fiber Layer and Ganglion Cell Layer. The Disc Damage Likelihood Scale enables clinicians to precisely diagnose and monitor glaucoma for Optic Nerve Head analysis.

Comprehensive Hood report

Structure + Function

Our S+F report allows clinicians to understand the relationship between structural glaucoma damage and the functional impact on the patient’s field of vision.  This provides a quick and comprehensive single-page report for glaucoma management.

Perform high-resolution posterior and anterior segment scans

Choose Your Scan Program

Retina

  • 3D Volume Scan
  • Radial Line Scan
  • Raster Line Scan
  • Retina Cross Scan
  • High Resolution Line Scan

Disc

  • 3D Volume Scan
  • Radial Line Scan
  • High Resolution Line Scan

Central

  • 3D Volume Scan
  • Raster Line Scan
  • Full Range Line Scan

Anterior

  • 3D Volume Scan
  • Radial Line Scan
  • Raster Line Scan
  • Anterior Cross Scan
  • Anterior Line Scan
  • Anterior Chamber Full-Range Line Scan
  • Anterior Chamber Full-Range Cross Scan
Anterior Segment Cross section Full Range Line

Optional Software Modules

Angiography OCT

Angiography OCT provides an alternative to the traditional fluorescein method. Although OCT-A will not completely replace FA imaging, it is a quick and non-invasive tool.  The software allows clinicians to observe, track and compare changes in the microvasculature of the retina in both eyes.

Learn More
Previous
Next
ikona topography

Topography

Topography OCT is a pioneering way to provide detailed corneal curvature maps. Anterior, Posterior surfaces and Corneal Thickness provide the True Net Curvature information. T-OCT™ is excellent when paired with the B-OCT® module for IOL surgery.

Learn More

Biometry OCT

B-OCT® is an excellent tool for any clinician who manages myopia control or performs cataract surgery. Biometry OCT provides a complete set of ocular parameters: Axial Length, Central Cornea Thickness Anterior Chamber Depth, Lens Thickness, Pupil size, and White to White.

Learn More
Screen Shot 2022-11-17 at 11.50.49 AM

IOL Calculation

IOL formulas allow the user to calculate IOL implant parameters. Our systems now support the latest IOL data base standard IOLCon.org so that you can always keep your library up-to-date.

Learn More

Image Gallery

Publications

Brochure

Technical Specifications

FUNDUS CAMERA

TypeNon-mydriatic fundus camera
Photography typeColor
Angle of view45° ± 5%
Min. pupil size for fundus3.3 mm
Camera12.3 Megapixel
PhotographyFundus (Retina, Central, Disc, Manual fixation), Anterior photo
Flash adjustment, Gain, ExposureAuto, Manual
Intensity levelsHigh, Normal, Low



OPTICAL COHERENCE TOMOGRAPHY

Technology
Spectral Domain OCT
Light SourceSLED Wavelength 850 nm
Bandwidth50 nm half bandwidth
Scanning speed80 000 measurements per second
Axial resolution2.8 μm digital, 5 μm in tissue
Transverse Resolution12 μm, typical 18 μm
Overall scan depth2.8 mm / ~6 mm in Full Range mode
Min. pupil size for OCT2.4 mm
Focus adjustment range-25 D to +25  D
Scan rangePosterior 5 mm to 15 mm, Angio 3 mm to 9 mm,
Anterior 3 mm to 18 mm
Scan types3D, Angio¹, Full Range Radial, Full Range B-scan, Radial (HD), B-scan (HD), Raster (HD), Raster 21 (HD), Cross (HD), TOPO ¹, Biometry AL¹
Fundus alignmentIR, Live Fundus Reconstruction
Alignment methodFully automatic, Automatic, Manual
Fundus TrackingReal time active, iTracking
Retina analysisRetina thickness, Inner Retinal thickness, Outer Retinal thickness, RNFL+GCL+IPL thickness, GCL+IPL thickness, RNFL thickness, RPE deformation, MZ/EZ-RPE thickness
Angiography OCT¹Vitreous, Retina, Choroid, Superficial Plexus, RPCP, Deep Plexus, Outer Retina, Choriocapilaries, Depth Coded, SVC, DVC, ICP, DCP, Custom, Enface, FAZ, VFA, NFA,
Quantifi cation: Vessel Area Density, Skeleton Area Density, Thickness map
Glaucoma analysisRNFL, ONH morphology, DDLS, OU and Hemisphere asymmetry, Ganglion analysis as RNFL+GCL+IP and GCL+IPL,
Structure + Function ³
Angiography mosaicAcquistion method: Auto, Manual
Mosaic modes: 10 mm x 6 mm, Manual up to 12 images
Biometry OCT ¹AL, CCT, ACD, LT, P, WTW
IOL Calculator ²IOL Formulas: Hoffer Q, Holladay I, Haigis, Theoretical T, Regression II
Corneal Topography Map ¹Axial [Anterior, Posterior], Refractive Power [Kerato, Anterior, Posterior, Total], Net Map, Axial True Net, Equivalent Keratometer, Elevation [Anterior, Posterior], Height, KPI (Keratoconus Prediction Index)
Anterior
(no lens/adapter required)		Anterior Chamber Radial, Anterior Chamber B-scan, Pachymetry, Epithelium map, Stroma map, Angle Assessment, AIOP, AOD 500/750, TISA 500/750, Angle to Angle view
ConnectivityDICOM Storage SCU, DICOM MWL SCU, CMDL, Networking
Fixation targetOLED display (the target shape and position can be changed), External fixation arm
Dimensions (LxWxH) / Weight479 mm × 367 mm × 493 mm / 30 kg
Power supply / consumption100 V to 240 V, 50/60 Hz / 90 VA to 110 VA

¹ An optional software module
² The Biometry module and a separate license for the IOL Calculator are required
³ Via connection with PTS software version 3.4 or higher
